Quick Answer: Ogee-Crested Weir With Pressure Measurement is a PVC fixed weir for the experimental flume with two crests: one with a chute and one with a chute and ski jump. Bores in the downstream face connect to integrated manometer tubes with a 290 mmwc measuring range.
Last updated: October 2026
Key Features
Weir crest with chute, 172 x 84 x 160 mm
Weir crest with chute and ski jump, 210 x 84 x 160 mm
Pressure bores perpendicular to the downstream surface
Heads shown directly on integrated manometer tubes
PVC weir body with sealing lips
Technical Specifications
Specification
Value
Manometer measuring range
290 mmwc
Weir with chute (L x W x H)
172 x 84 x 160 mm
Weir with chute with ski jump (L x W x H)
210 x 84 x 160 mm
Weir body
PVC, with sealing lips
Total weight
Approx. 4 kg
About This Product
Ogee-crested weirs are fixed control structures often used to dam a river, and their downstream side is shaped to improve flow and pass the largest possible discharge. Fitted in the EXPERIMENTAL FLUME FLOW CHANNEL APPARATUS, this weir lets students measure the pressure distribution along its downstream side for different discharges, observe nappe separation and compare theoretical with measured discharge.
Frequently Asked Questions
Q1. How is pressure measured on the ogee-crested weir? Through bores perpendicular to the surface of the downstream side. The heads are read directly on the integrated manometer tubes, which have a measuring range of 290 mmwc.
Q2. What experiments can be carried out with the weir? Hydrodynamic overfall, pressure distribution along the downstream side for different discharges, nappe separation, determination of discharge and head, and comparison of theoretical and measured discharge.
