Quick Answer: Electrophoresis Power Supply is a power unit with three sets of output connectors for running up to three chambers at once, giving a maximum output of 55 W and 500 mA at 25 V, 75 V or 110 V.
Last updated: October 2026
Key Features
Three sets of output connectors run up to three chambers simultaneously
Voltage: 25 V, 75 V or 110 V
Maximum output 55 W; maximum current 500 mA
LED screen and illuminated power switch
Overcurrent protected
Power input: 230 V AC, 50/60 Hz
Technical Specifications
Specification
Value
Maximum output
55 W
Variable voltage
25 V, 75 V, 110 V
Maximum current
500 mA
Power input
230 V AC, 50/60 Hz
Outputs
Three sets of output connectors
Display
LED screen
Protection
Overcurrent protected
About This Product
Up to three electrophoresis chambers can be run from this unit at the same time, each on its own set of output connectors, with the voltage chosen from 25 V, 75 V or 110 V. The LED screen, illuminated power switch and overcurrent protection make it a practical bench supply for Biology Lab Equipment set-ups that run several chambers together.
Frequently Asked Questions
Q1. How many electrophoresis chambers can the power supply run at once? It has three sets of output connectors, so up to three chambers can be run simultaneously.
Q2. What voltages does the Electrophoresis Power Supply provide? Voltage is listed as 25 V, 75 V and 110 V, with a maximum output of 55 W and a maximum current of 500 mA.
Q3. What power input does it need? It runs on a 230 V AC, 50/60 Hz power input.
