Wheatstone Bridge Laboratory Kit

Wheatstone Bridge Laboratory Kit

Product Code : SCL-EAE-11163

Quick Answer: Wheatstone Bridge Laboratory Kit is a physics bridge apparatus for null-point detection and measuring an unknown resistance by the Wheatstone bridge method, built around 24 SWG constantan wire, a wooden metre scale and a pencil jockey.

Last updated: October 2026

Key Features

  • Wheatstone bridge method for known and unknown resistances
  • 24 SWG constantan bridge wire
  • Wooden metre scale for balance-length readings
  • Pencil jockey for point contact along the wire

Technical Specifications

SpecificationValue
Bridge wire24 SWG constantan
ScaleWooden metre scale
JockeyPencil jockey

About This Product

As one of the electricity experiment kits for schools in the Electrical And Electronics range, it is set up with a galvanometer, resistance box, key and low-voltage DC source. The jockey is touched lightly on the wire and moved until the galvanometer reads zero or minimum, and that balance length is used to calculate the unknown resistance.

Frequently Asked Questions

Q1. Why is a galvanometer used with the Wheatstone Bridge Laboratory Kit?
It detects the null point: at balance the galvanometer shows zero or minimum deflection, which allows the unknown resistance to be calculated.

Lab Equipments Ambala exports to schools, colleges and distributors in countries such as Senegal, Egypt and Ecuador.

Contact Lab Equipments Ambala for a quotation on the Wheatstone Bridge Laboratory Kit.
