Quick Answer: Inclined Plane Brass has a 15 x 60 cm glass-topped wooden board hinged on an iron base with a graduated arc, and it can be clamped at any angle up to 45 degrees.
Last updated: October 2026
Key Features
Wooden board 15 x 60 cm, glass-topped
Hinged on an iron base with a sector carrying a graduated arc and vertical scale
Clamps at any angle up to 45 degrees
5 cm frictionless pulley on a clamp adjustable to any position
Brass roller, cart and pan included; weights not included
Technical Specifications
Specification
Value
Board
Wooden, glass-topped, 15 x 60 cm
Base
Iron, hinged
Angle
Any angle up to 45 degrees
Angle scale
Sector with graduated arc and vertical scale
Pulley
5 cm, frictionless, on adjustable clamp
Supplied with
Brass roller, cart and pan; no weights
About This Product
The glass-topped board is hinged on its iron base and read against a graduated arc and vertical scale, so the slope can be clamped at a known angle up to 45 degrees. The 5 cm pulley clamps at the end in any position needed, and the brass roller, cart and pan come with it for Applied Mechanics experiments. Weights are not part of this mechanics lab equipment set.
Frequently Asked Questions
Q1. What angles can the Inclined Plane Brass be set to? The plane may be clamped at any angle up to 45 degrees.
Q2. What accessories are supplied? A brass roller, cart and pan, along with the 5 cm frictionless pulley on its clamp; weights are not included.
