Vacuum Extractor Bird Anterior and Posterior Cups Set
Product Code : EL-HE-10948
Quick Answer: Vacuum Extractor Bird Anterior and Posterior Cups Set is a complete vacuum extractor system to assist vaginal deliveries, with an electrically powered pump adjustable from 0 to approx. -90 kPa / -675 mmHg and Bird type anterior and posterior cups. It comes on a matching trolley with a foot pedal.
Last updated: October 2026
Key Features
- Electrically powered vacuum/suction pump, suction flow up to approx. 30L/min
- Vacuum adjustable from 0 to approx. -90 kPa / -675 mmHg, shown on a dial gauge in kPa and mmHg
- Servo system restarts suction to compensate for loss of vacuum
- Bird type cups: 2 anterior (50 and 60 mm) and 1 posterior (50 mm), plus 2 soft cups
- Foot pedal with operate/stop switch
- Matching trolley on 4 antistatic swivel castors, all with brakes
Technical Specifications
| Specification | Value |
|---|---|
| Suction flow | Maximum approx. 30L/min |
| Vacuum range | 0 to approx. -90 kPa / -675 mmHg, adjustable |
| Gauge graduation | 5kPa / 37.5 mmHg |
| Gauge accuracy | Approx. 2.5 % |
| Power requirements | 220V/50Hz |
| Power consumption | 50W |
| Collection bottle | Plastic (PSU), autoclavable, with filter |
| Cups and handles | Stainless steel, chrome plated |
| Autoclaving | Relevant parts at 121°C |
| Trolley | 510 x 470 x 985 mm (l x w x h); castors approx. 100mm; carrying capacity approx. 15kg |
| Set includes | 2 extraction handles, 2 anterior cups, 1 posterior cup, 2 soft cups, 20 polypropylene bottom plates, collection bottle with lid and spare bottle, spare tube 3m, foot pedal, 5m power cable, trolley, parts list, instructions |
About This Product
During assisted vaginal deliveries, the electrically powered pump creates and maintains the vacuum at the extraction cup, and a servo system starts suction again whenever vacuum is lost. The operator reads the actual vacuum on the front-panel dial gauge and uses the foot pedal's operate/stop switch. Every part of this Hospital Equipment set can be disassembled and the relevant parts autoclaved at 121°C; the device needs routine maintenance, which can be handled where it is used.
Frequently Asked Questions
Q1. Which cups are included in the vacuum extractor set?
Two Bird type anterior cups (50 and 60 mm opening diameter), one Bird type posterior cup (50 mm) and two soft cups (50 and 60 mm), with 2 extraction handles.
Q2. What vacuum range does the extractor provide?
Vacuum is adjustable from 0 to approx. -90 kPa / -675 mmHg, with suction flow up to approx. 30L/min.
Q3. Can the parts be autoclaved?
All parts can be disassembled, and the relevant parts can be autoclaved at 121°C.
